Remote control float valve
Product model:W811/W831
        Juhan Valve's W811 / W831 remote control float valve is hydraulically driven to maintain the water level in the storage tank. At a relatively stable level, the float control switch is installed at the high level of the storage tank and is connected to the main valve through a pipeline. When rising and exceeding the maximum water level, the float switch is completely closed and the valve is automatically closed.
         When the water level drops to the lowest limit, the float switch is fully opened, and the valve is automatically opened for water replenishment, until the water level in the water tank is controlled within the stable ideal range.
         If the optional non-return feature is added, when the reverse pressure is generated, the returned liquid enters the air chamber to close the valve, preventing the liquid from returning.

Product Highlights
         Precise and repeatable water level control, ideal slow opening and slow closing functions, reliable full hydraulic control, reliable airtightness, large flow rate, built-in filter device to prevent piping system from being blocked.

Product parameters
Working pressure level Interface form and standard Temperature, medium Pilot parameters
PN10 / PN16 / PN25 / 150LB / 10K / 16K Flange connection:GB 1 ANSI/ BSEN/ISO/DIN/JIS 0°C~80°CRoom temperature water Controller: 1/2 * float switch

Part name Material
Valve body Ductile iron / stainless steel
Valve cover Ductile iron / stainless steel
Spring Stainless steel
Diaphragm NBR / VITON
Ball valve Brass / stainless steel
Needle valve Brass / stainless steel

DN 50 65 80 100 125 150 200 250 300 350 400 450 500 600
L 230 290 310 350 400 480 600 730 850 850 1100 1100 1250 1450
H 139 159 179 214 214 333 407 476 526 526 624 624 720 835
H1* 85 95 102 112 127 145 172 205 232 262 292 325 360 425
ФK 173 198 226 265 265 351 436 524 606 606 741 741 1002 1308
S 3/8 " 3/8" 3/8" 1/2" 1/2" 1/2" 3/4" 1" 1" 1 " 1 1/2" 1 1/2" 2" 2"
Weight(Kg) 1 4 1 9 23 32 45 68 1 25 20 0 2 60 31 0 5 60 620 8 80 130 0

Applications
